Anderson Power Products has released a catalog that covers the Powerpole and Multipole (SB, SBX, SBE, SBO, SBS) connectors. The updated catalog has a clean modern aesthetic focused on ease of use. Product selection guides provide an overview of the features and specifications by connector, thereby allowing speedy navigation to appropriate pages.
The new 3 Pole Finger Proof SBS 75G connector is introduced in this catalog. The SBS 75G features wire and PCB connectors with an IEC60950 touch safe interface UL rated for up to 110A, 600V ac or dc per pole. The center contact is make-first, break-last in relation to the other two positions and is UL rated for grounding as well as power.
Up to date specs make it easier to select a connector. APP has retested the largest wire size of all Powerpole and SB connectors to the current UL parameters. Retesting produced substantial changes in UL ampere ratings. For example, the SB50 connector previously had a UL rating of 50A but now carries a 120A rating with a suitable 6 AWG size wire. The new catalog is in stock, part number CAT-PPMP. The electronic version of the catalog is here:: http://www.andersonpower.com/litlib/files.html/download/498 .
Anerderson Power Products
www.andersonpower.com
